Average Heat Pump Weight For The Curious Mind
Heat pump weight is not something a lot of people think about. But if you have to know, I have created some rather boring statistics.
You can see from the data below that a residential heat pump weighs anywhere from about 135 to 280 pounds mostly depending on the BTUs.
My charts contain information related to 14 SEER heat pumps. As the SEER ratings go up so will the weight, just slightly.
Shipping weight was available for some units, but it’s safe to say that about 10 pounds of pallet and cardboard are sufficient to cover that added weight.
This is an info alert. This is an affiliate site and links will take you to offers that you will not be obligated to buy and you will not have to pay more.
Along with the weight below, there are some links and images that will send you to Amazon and you can price compare.
Goodman Heat Pump Weight By BTUs
I’m kind of partial to Goodman heat pumps. They are price right and I’m having good experience with the dependability. In 2019 I had a call on one I’d installed just over 10 years prior. It had a bad contactor.
It’s the first of many that I’ve had to go back on, and for a rather common issue with HVAC equipment.
| Capacity In Tons | BTU’s | Weight lbs/kg | Shipping Weight lbs/kg |
| 1.5 | 18,000 | 143/ 64.86 | 154/69.85 |
| 2 | 24,000 | 143/64.86 | 154/69.85 |
| 2.5 | 30,000 | 171/77.56 | 182/82.55 |
| 3 | 36,000 | 173/ 78.47 | 184/83.46 |
| 3.5 | 42,000 | 191/86.64 | 207/93.89 |
| 4 | 48,000 | 273/123.83 | 288/130.64 |
| 5 | 60,000 | 277/125.65 | 292/132.45 |
Rheem Heat Pump Weight By BTUs
Rheem and Ruud, kind of like Chevy and GMC are everywhere in my neck of the high desert. They have provided a lot of people with good dependable and economical heating and cooling.
I just have to remind everyone that’s interested in new HVAC equipment that it’s not who makes the best heat pump, it’s who does the best job at installing.
| Capacity in Tons | BTU’s | Weight lbs/kg | Shipping Weight lbs/kg |
| 1.5 | 18,000 | 151/68.49 | 158/58.06 |
| 2 | 25,000 | 146/66.22 | 153/69.40 |
| 2.5 | 30,000 | 155/70.31 | 162/73.48 |
| 3 | 36,000 | 177/80.29 | 184/83.46 |
| 3.5 | 42,000 | 201/91.17 | 208/94.35 |
| 4 | 48,000 | 227/102.97 | 234/106.14 |
| 5 | 60,000 | 262/118.84 | 269/122.02 |
Carrier Heat Pump Weight By BTUs
Carrier does not support the Amazon community and it’s easy to understand why. It’s difficult for a contractor to present a quote to a customer and then that customer price shops on Amazon or the internet in general.
I had this happen recently. My customer left a note at the bottom of there invoice telling me that my prices were a lot higher that Amazon. My simple answer is, “I don’t compete with Amazon.”
When parts enter my service truck for stock, the prices go up.
| Capacity in Tons | BTU’s | Weight lbs/kg | Shipping Weight lbs/kg |
| 1.5 | 18,000 | 136/61.69 | N/A |
| 2 | 24,000 | 144/65.32 | N/A |
| 2.5 | 30,000 | 158/71.67 | N/A |
| 3 | 36,000 | 170/77.11 | N/A |
| 3.5 | 42,000 | 201/91.17 | N/A |
| 4 | 48,000 | 158/71.66 | N/A |
| 5 | 60,000 | 212/96.16 | N/A |
Trane Heat Pump Weight By BTUs
Don’t think you’ll find Trane equipment on Amazon
I’ve always respected the way Trane builds their units. Always a little heaver on the cabinets, as you can see compared to the others in this post.
| Capacity in Tons | BTU’s | Weight lbs/kg | Shipping Weight lbs/kg |
| 1.5 | 18,000 | 194/88.00 | 222/100.70 |
| 2 | 24,000 | 197/89.36 | 225/102.06 |
| 2.5 | 30,000 | 200/90.72 | 228/103.42 |
| 3 | 36,000 | 211/95.71 | 240/108.86 |
| 3.5 | 42,000 | 273/123.83 | 238/107.96 |
| 4 | 48,000 | 249/112.95 | 285/129.27 |
| 5 | 60,000 | 300/136.08 | 335/151.95 |
Lennox Heat Pump Weight By BTUs
I’m still searching for the unit weight minus the shipping carton and pallet. Seems Lennox deemed it unnecessary for the general public. Pretty safe to say that the shipping weight minus about 15 lbs or 6.8 kg should give you an accurate enough assumption of the units pressure upon the ground (weight).
No Lennox on Amazon either. It’s been said over the years that manufacturers don’t sell to the public to protect there dealer from DIY’ers and those that are not trained to make a proper installation.
| Capacity in Tons | BTU’s | Weight lbs/kg | Shipping Weight lbs/kg |
| 1.5 | 18,000 | N/A | 177/80.29 |
| 2 | 24,000 | N/A | 177/80.29 |
| 2.5 | 30,000 | N/A | 177/80.29 |
| 3 | 36,000 | N/A | 202/91.63 |
| 3.5 | 42,000 | N/A | 272/123.38 |
| 4 | 48,000 | N/A | 273123.83 |
| 5 | 60,000 | N/A | 295/133.81 |
Conclusion Of Heat Pump Weight Plus Some Questions
My conclusion to the data would be a question. Why are you looking for heat pump weight? Are you planning on moving and taking your heat pump with you? Not good.
Or relocating your unit and want to know what kind of a strain you’re about to put upon your back.
Oh, I just came up with another reason. Your pad is unlevel and you want to make it look good because you’re selling your house or you just like things to look aesthetically pleasing. In that case read this article about how to easily lift a unit to level or replace the pad.
Please leave a comment below and tell me.
